IR Break Beam Sensor Solar Powered Wireless Perimeter Security Alarm System Outdoor/in

Not rated yet

Solar Powered Wireless Perimeter Alarm System

The solar powered wireless perimeter alarm system is designed to help you protect your family, home or business. It comprises of a set of detection beams packed with quality features and a versatile 4 Zone indoor receiver, The beams have up to 100 yards detection range, multi beam detection technology to stops false alarms from insects, small animals etc and up to 800 yards transmission range. (All ranges are based on clear line of sight)

    • 20% off
    $249.99, save $50.00
  • $199.99

Affordable & Versatile Security System

The system works by installing the perimeter beams (additional sets can be added) in a location that you need to protect The beams can be up to 100 yards away from each other. Plug the indoor receiver into a standard wall socket (Up to 800 yards away from detection beams). When a vehicle or person passes through the beams the receiver will chime and activate any accessory connected to it. The receiver can have a multitude of accessories connected to it (optional) such as wireless sirens, wired sirens & GSM auto-dialer. You can even hook it to your DVRs trigger input(s) to record on detection or send alerts such as emails. You are only limited by your DVR’s capabilities and features.

Solar Powered Wireless Beam Detector:

Detector Size: 340 (H) X 123 (W) X 45 (D) mm
Power Supply: Re-Chargeable Batteries (Making For Easy Wireless Installation)
Charging Method: Built In Solar Panels (DC input on back for optional charging options such as extra solar panels)
Multi Detecting Beams: (Prevents False Alarms From Small Animals And Moving Debris)
Detection Range: 100 Yards Between Detectors (Line Of Sight)
Wireless Range To Receiver: Impressive 800 Yards (Line Of Sight)
Quality construction
Mounting Methods: Supplied With Wall & Pole Mounting Brackets
Test Light: (For Easy Installation, Actual Detector Beams Are Invisible To The Naked Eye)
Frequency: 433 MHz
IP Rating: Ip66
Distance Between Detection Beams: 60mm

Wireless Multifunction Receiver:
Receiver Size: 160 (W) X 105 (H) X 35 (D) mm
Power Supply: 12v DC Outputs (Adjustable Channels & Time Duration)
ON/OFF Button: Yes
Adjustable Volume Control: Yes
Available Channels: 4 X Dry Relay Outputs (Adjustable Channels)
Max Sets Of Beams Per Zone: 32
Maximum Sets Of Detectors Per Receiver: 128
Output Voltage: 12v DC
Output Voltage Duration: 1, 10, 60 Second & 5 Minutes
Built In Chimes: Yes (One Per Channel)
Reminder Bleep: Yes (If Programmed)
Exit Delay: Yes 5 Minutes
Frequency: 433 MHz
Standby Current: 20 Ma
Alarm Current: 180 Ma
Relay Rating: 24v DC Or 120v AC (2 Amp)
Wireless Working Range: 800 Yards (Line Of Sight, Depending On Which Detectors Are Being Used)

Easy to install:

The lack of power wiring needed for the Perimeter detectors means you can place them in obscure out of the way places where power maybe difficult to get to. The perimeter beams need to be mounted facing each other, they are very easy to install as they have a built in red glow light (for easy shorter length lining up) which illuminates for a while after switching the beams on, after a while this light will automatically switch off adding to your security.
The dual detection technology is made up of multiple detecting beams (60 mm apart), which need to be activated at the same time, before the alarm signal is sent back to the receiver. This reduces false alarms from small animals, leaves, debris, rain etc.
You can easily add additional beams, sirens & indoor/outdoor receivers to this system at any time.


Easy Programming:

Turn on beams (Switch’s On Rear).
Mount the beams.
Line up by eye or string line / laser pen Etc for longer distances
Put the relevant receiver into learn mode on the zone of your choice (1 through 4)
Walk through the beams, at this time (providing you have them correctly lined up) a bright red glow will illuminate.
The signal sent to the receiver from this set of beams will be programmed into the relevant receiver.
Take the receiver out of learn mode.
The system is now ready.

What You Receive With This System

1 X 4-Channel Indoor Receiver
1 X Wall Power Supply for Receiver
1 X Rear Mounting Bracket for Receiver
1 X Wireless Hand Held Remote
1 X Receiver Manual
1 X Solar Powered Detecting Beam Set (additional sets can be added at any time)
1 X Set Of Wall Mounting Brackets (included for each sensor set)
1 X Set Of Pole Mounting Brackets (included for each sensor set)
1 X Setup Instructions
